High Tensile strength EVA Rubber Track Rail Pads , Railway Plate

Basic Information
Place of Origin: China
Brand Name: ZhongYue
Certification: ISO9001:2015
Model Number: Rubber Pad
Minimum Order Quantity: 10000pcs
Price: Negociable
Packaging Details: Export Carton or as customer requirement
Delivery Time: 15-30days after order confirmation
Payment Terms: T/T, 30% in advance
Supply Ability: 2000T/month
Material: EVA,HDPE Or Rubber Brand Name: Zhongyue
Dimensions (L X W X H) (mm):: According To Drawing Or Samples QC: ISO,TUV
Specification: According To Drawings Application: Plastic Dowel
Warranty: 3 Years Surface Treatment: Plain Oiled
Customized: According To Drawings
High Light:

rubber track pads

,

railway parts

High Tensile strength EVA Rubber Track Rail Pads , Railway Plate ​


Zhongyue specialize in producing rail fastening , .Rail pad lies between the rails and base plates to keep the rail stably , they made of HDPE/EVA/Rubber to preclude and buffer impact ,increase friction and reduce vibration , we produce the rail pad for E type rail fastening system and SKL type rail fastening system . The following is the properties of the HDPE/EVA/Rubber .


Brand

Zhongyue

Name

rail pad

Type

For rail UIC54, UIC60, BS80lbs,BS100lbs, and size as ordered

Material

HDPE

EVA

Rubber

Technical spec.

Density: 0.95-0.98g/cm3
Tensile strength: ≥19Mpa
Elongation: >80%
Melting point: 170-190°C
Insulation resistance:
≥1×1010Ω
Hardness:≥98A

Density:0.95-0.98gcm3
Tensile strength:≥15Mpa
Elongation: >500%
Melting point: 170-190°C
Insulation resistance:
≥1×1010Ω
Hardness: ≥90A

Hardness:75±5A
Tensile strength: ≥12.5N/mm²
Elongation: ≥250%
Operating temperature:
 -25°C~100°C

Color

Black




High Tensile strength EVA Rubber Track Rail Pads , Railway Plate 0



HDPE

No.

Technique parameter

Unit

Technical requirement

Value

1

Density

g/㎝3

0.95-0.98

0.95

2

Tensile strength

Mpa

≥19

19

3

Elongation

%

>80

150

4

Melting point

170-190

190

5

Insulation resistance

Ω

≥1×1010

3.5×1010

6

Hardness

A

≥98

98(A)



 EVA : polyethylene 80%, Vinyl Acetate 20%

No

Technique parameter

Unit

Technical requirement

Value

1

Density

g/㎝3

0.95-0.98

0.95

2

Tensile strength

Mpa

≥15

16

3

Elongation

%

>500

550

4

Melting point

170-190

170

5

Insulation resistance

Ω

≥1×1010

5.0×1010

6

Hardness

A

≥90

92(A)


Rubber

No.

Technique parameter

Unit

Value

1

Stiffness


KN

90-130

2

Hardness shore A


72-80degree

3

Electronic Resistance


Ω

≥106

4

Tensile strength before aging


Mpa

≥12.5

5

Elongation before aging


%

≥250


As a leading manufacturer of rail fastening in China , SUYU also can produce many other railway fasteners , such as track bolt . Sleeper screw . track spike .tie plate .rail clips ,elastic rail clip .SKL tension clamp .rail shoulder and so on .

Sticking to the “quality first” policy, Zhongyue pays great attention to quality control management. We have granted ISO9001-2000 certificates and have got the production license of China’s Railway Ministry on railway products.  We have a full set of inspection instruments which makes sure all the products produced by us should be of high quality and up to customers’ requirements.


High Tensile strength EVA Rubber Track Rail Pads , Railway Plate 1

High Tensile strength EVA Rubber Track Rail Pads , Railway Plate 2
