| Place of Origin: | China |
|---|---|
| Brand Name: | ZhongYue |
| Certification: | ISO9001:2015 |
| Model Number: | Rail Clip |
| Minimum Order Quantity: | 2000sets |
| Price: | Negociable |
| Packaging Details: | 25Kg plastic bags and wooden pallets or according to clients' requirement |
| Delivery Time: | 10 working days after received your payment |
| Payment Terms: | T/T, 30% in advance |
| Supply Ability: | 500,000pcs per month |
| Product Name: | Rail Clip | Application: | Railway Fastening |
|---|---|---|---|
| Type: | KPO3, KPO6, KPO9, Or Customized | Material: | Q235-forging, ZG35-cast Steel, QT500-7-cast Iron |
| Surface: | Plain (oiled) | Standard: | DIN5906 |
| Dimensions: | According To Drawings | Rail: | ASCE30, ASCE50, UIC60, UIC54,BS90A,BS80A,115RE Etc |
| High Light: | crane rail clips,din rail clips |
||
The rail clip is one of the components which ensure that rails will be fixed to ground. Rail clips undertake
rail movements synchronously thanks to the synthetic elastomer vulcanized to clip permanently in the
portion to be contacted with rail.
We have extensive experience in the rail industry and a high level of expertise in this specialized field. Our
rail clip products are designed in such a way to allow fine adjustment for alignment, while at the same time
, providing a self locking effect against the force of the crane. The rail clips can be fixed by being bolted or
welded to the structure.
|
Brand |
ZHONGYUE |
||
|
Name |
Railroad Fsatener Crane Rail Clip for North Africa, K type KPO MTH railway clip |
||
|
Type |
KPO3, KPO6, KPO9 |
||
|
Or the type by customers’ drawings |
|||
|
Material |
Q235-forging |
ZG35-cast steel |
QT500-7-cast iron |
|
Chemical composition(%) |
C:0.12-0.20, Mn:0.30-0.70, Si:≤0.3, P:≤0.045, S:≤0.045 |
C: ≤0.4, Mn:≤0.9, Si: ≤0.5, P:≤0.04, S:≤0.04 |
C:3.60-3.80, Mn:≤0.6, Si:2.50-2.90, P:≤0.08, S:≤0.025 |
|
Surface |
plain (oiled) |
||
|
Standard refers |
DIN5906 |
||
Double-layer woven bag+free-fumigation pallet; Steel Drum+Pallet; Wooden box; or upon customers' request.
Drawing
Other Rail Clip We Supply
Our main products:
Plastic and rubber pads, EVA pad, HDPE pad, dog spike, screw spike, railway bolt and nut, washer, rail clip, rail shoulder, crane rail, fish plate, base plate, crane rails and so on.
1. Q: what information should we show if we need price?
A: 1. tree species;
2. size: length*width*thicknessl;
3. quantity;
4. we adopt oiled anti corrosion, if yours special, please mark it.
2.Q: what is anti-corrosion?
A: Using high temperature and pressure oiling corrosion technology.
Technology standards : GB9221-88
3. Q: payment terms?
A: 30% by T/T as deposit, the balance 70% before delivery.
4. Q: Validity Date?
A: 10~15 days in general. it will be showed in quotation.
5. Q: Mold fee?
A: if we have same mold, no mold fee;
if we make new mold with small quantity, client pay for it;
if we make new mold with large quantity, SuYu pay for it.
If you have any other models of rail/ rail fastener, welcome to contact me.
