Q235 60Si2MnA 60Si2CrA Rail Fastening System Railway Fasteners

Basic Information
Place of Origin: China
Brand Name: ZhongYue
Certification: ISO9001:2015
Model Number: E Type Rail Fastening System
Minimum Order Quantity: 10000sets
Price: Negociable
Packaging Details: according to clients' requirement
Delivery Time: 10 working days after received your payment
Payment Terms: T/T, 30% in advance
Supply Ability: 500,000pcs per month
Material: Q235(main) 60Si2MnA, 60Si2CrA, 55Si2Mn, 38Si7 Application: Fastening Part
Certification: ISO9001:2008 Main Surface Treatment: Plain (oiled), Oxide Black, Color Painting
Standard Refers: DIN17221, BS970, GB/T1222 Name: Rail Fastening Railway Fasteners Railway Equipment Supply
High Light:

railway track fasteners


vossloh fastening system

rail fastening railway fasteners railway equipment supply



SKL fastening system
ZhongYue rail fastening railway fasteners railway equipment supply
Meet all the requirements of Tram line. Top-down construction method is available, so sleepers are no needed. It can be used in general line, also in turnout area. It is feasible in open track, also in embedded track. Easy installation, Gauge adjustment +/-10mm, height regulation +20mm. The static stiffness is no less than 30KN/mm, different stiffness of rail pad can be provided according the requirements of customers.

Technical Parameters

Part name





E clip

Dia. 16mm

Dia. 18mm

Dia. 20mm



Plain oiled,

color painting,

or the other

custom finish

Hardness: 44-48HRC
Toe Load: 500-700kgf for Dia.16mm
750-900kgf for Dia.18mm
1100-1400kgf for Dia.20mm
Fatigue life:3 millions cycles

without breaking for Dia.18mm,

5 millions cycles without breaking

for Dia.20mm
Standard: DIN17221, BS970,




115RE,50kg rail,

60kg rail,BS80lbs,




Plain oiled,

color painting

Different designs are available.

Rail pad



in ordered size


or rubber

Black or other colors

Different designs are available.



50kg rail, 60kg rail,


and size as ordered


Nylon 66 (PA66)

Black, blue,

yellow, green

or other colors

Different designs are available.



Order Hints:

MOQ: based on your product

Delivery time:Within 30days after order confirmed

Shipment: sea freight

Payment term: T/T 30% deposit, balance before shipment; LC



Our product range:

1. Screw spike/Coach screw/Drive screw/Sleeper Screw, Dog spike/Railroad spike/Lock spike/Cut spike,etc.
2. Rail clip/ Tension clamp/ E, R, SKL clip/ DP clip/ Deenik clip
3. Swivel Bolts/ Track Bolt/ Special bolts/ U bolts/ J bolts/ Anchor bolts/ Foundation bolts/ Stud bolts/ Rod bolts/ Curved bolts/ Tunnel bolts
4. Tie plate/ Base plate / Rail plate/ Rail fixing base/ Rail Pads/ Sole plate/ Sole pad
5. Fish plate / Joint bar / Rail joint/ Splice Bar
6. Track bolt/ T bolt / Rail bolt/ Clamp bolt/ Inserted bolt/ Clip bolt/ Fish bolt/ Square bolt/ Rod bolt /Rail joint bolt
7. Clamp plate/ Rail spring clamp/ Anchor plate/ Steel clip
8. Rail Shoulder/ Rail sleeper Inserts/ Rail Anchors for rail sleepers
9. Plastic dowel / Guide plate/ Nylon insert
