| Place of Origin: | China |
|---|---|
| Brand Name: | ZhongYue |
| Certification: | ISO9001:2015 |
| Model Number: | Railway Bolt |
| Minimum Order Quantity: | 5000pcs |
| Price: | Negociable |
| Packaging Details: | Plastic bags and wooden pallets or according to clients' requirement |
| Delivery Time: | 30 days after received your payment |
| Payment Terms: | T/T, 30% in advance |
| Supply Ability: | 500,000pcs per month |
| Product Name: | Button Head Oval Neck Grade 4.6 5.6 5.8 Track Bolts And Nuts | Material: | Q235. 35#. 45#. 40Cr |
|---|---|---|---|
| Grade: | 4.6 4.8 5.6 8.8 10.9. | Main Surface Treatment: | Plain (oiled), Oxide Black, Zinc, HDG, Wax, Bitumen, Dacromet |
| Warranty: | Two Years | Certificate: | ISO9001, SGS |
| High Light: | hexagon head bolt,steel bolts and nuts |
||
Standard:DIN, JIS, ISO, ANSI, ASME, BS, AS
Grade:4.8/ 8.8/ 10.9/ 12.9
Dimensions:M8, M10, M12, M14, M16, M18, M20, M22, M24 and so on
Surface Treatment:Zinc-plated, Plain, Black Anodize, Dacroment
| Brand | ZhongYue | |||
| Name | Railway bolt | |||
| Type | HS26/HS32 | |||
| Russian clamp bolt & inserted bolt | ||||
| Or the type by customers’ drawings | ||||
| Grade | 4.6 | 5.6 | 8.8 | 10.9 |
| Material | Q235 | 35# | 45# | 40Cr |
| Mechanical properties | Tensile strength: ≥400Mpa | Tensile strength:≥500Mpa | Tensile strength:≥800Mpa | Tensile strength:≥1000Mpa |
| Yield strength:≥240Mpa | Yield strength:≥300Mpa | Yield strength:≥640Mpa | Yield strength:≥900Mpa | |
| Elongation:≥22% | Elongation:≥20% | Elongation:≥12% | Elongation:≥9% | |
| Cold bending: 90 degree without crack | Cold bending: 90 degree without crack | Cold bending: 90 degree without crack | Cold bending: 90 degree without crack | |
| Surface | plain (oiled), Oxide black, Zinc, HDG, wax, bitumen, Dacromet, Sherardizing | |||
| Standard refers | UIC864-2 | |||
Advantage:
We are a leading and reputed manufacturer of qualified railway products in China since 2013, have got the production license of China’s Railway Ministry on railway products. We supply to Thailand Railway, Indonesia Railway, Zambia Railway, American Railway etc for years. We can customize your product with ASTM, DIN, BS, JIS, AS, NF, ISO and GB standard, competitive price available.
Order Hints:
MOQ: based on your product
Delivery time:Within 30days after order confirmed
Shipment: sea freight
Payment term: T/T 30% deposit, balance before shipment; LC
