| Place of Origin: | China |
|---|---|
| Brand Name: | ZhongYue |
| Certification: | ISO9001:2015 |
| Model Number: | ZHONGYUE06 |
| Minimum Order Quantity: | 5000pcs |
| Price: | Negociable |
| Packaging Details: | 25kg plastic bag or carton in wooden pallet , 36 bags or cartons / pallets , 24pallets / container |
| Delivery Time: | 25-35 days after placing the order |
| Payment Terms: | T/T, 30% in advance |
| Supply Ability: | 1000 ton / month |
| Product: | L Bolt | Material: | Steel 45# |
|---|---|---|---|
| Surface: | Galvanised, HDG. | Size: | From M16 To M30, Customized Length |
| Application: | Fastening | Grade: | 8.8 |
| High Light: | railroad bolts,steel bolts and nuts |
||
SGS Stainless Steel Bolts Galvanised Bent Anchor Bolts For Fastenings
Galvanised Bent Anchor Bolts / L-Shaped Bolts
L-shaped bolts that are embedded into concrete and used to anchor construction supports like columns, floor plates, sign structures, structural steel columns, light poles, highway sign structures, bridge rails, equipment, and other applications.
ZHONGYUE manufactures custom bent anchor bolts from 16mm to 30mm diameter to virtually any ASTM specification. They are provided either plain finish or hot-dip galvanized. Stainless steel anchor bolts are also manufactured. All operations, including the galvanizing process, are performed in our factory.
Technical Specifications
| Grade | 4.6 | 5.6 | 8.8 | 10.9 |
| Material | Q235 | 35# | 45# | 40Cr |
|
Mechanical properties |
Tensile strength: ≥400Mpa |
Tensile strength: ≥500Mpa |
Tensile strength: ≥800Mpa |
Tensile strength: ≥1000Mpa |
|
Yield strength: ≥240Mpa |
Yield strength: ≥300Mpa |
Yield strength: ≥640Mpa |
Yield strength: ≥900Mpa |
|
| Elongation:≥22% | Elongation:≥20% | Elongation:≥12% | Elongation:≥9% | |
|
Cold bending: 90 degree without crack |
Cold bending: 90 degree without crack |
Cold bending: 90 degree without crack |
Cold bending: 90 degree without crack |
|
| Surface | plain (oiled), Oxide black, Zinc, HDG, wax, bitumen, Dacromet, Sherardizing | |||
| Standard refers | UIC864-2 | |||
Photos for reference:
Our main products:
1. Q: what information should we show if we need price?
A: 1. tree species;
2. size: length*width*thicknessl;
3. quantity;
4. we adopt oiled anti corrosion, if yours special, please mark it.
2.Q: what is anti-corrosion?
A: Using high temperature and pressure oiling corrosion technology.
Technology standards : GB9221-88
3. Q: payment terms?
A: 30% by T/T as deposit, the balance 70% before delivery.
4. Q: Validity Date?
A: 10~15 days in general. it will be showed in quotation.
5. Q: Mold fee?
A: if we have same mold, no mold fee;
if we make new mold with small quantity, client pay for it;
if we make new mold with large quantity, SuYu pay for it.
If you have any other models of rail/ rail fastener, welcome to contact me.
