Railway Fish Plates, rail joint bars for joint rail fish plate in railway

Basic Information
Place of Origin: China
Brand Name: ZhongYue
Certification: ISO9001:2015
Model Number: Customized models
Minimum Order Quantity: 1000pcs
Price: Negociable
Packaging Details: In Bundle with pallets
Delivery Time: 10 working days after received your payment
Payment Terms: T/T, 30% in advance
Supply Ability: 500000pcs each month
Product Name: Ordinary Rail Joints Fish Plates Joint Bars On A Railway Track Application:: Connect Or Joint Rail Tracks
Type:: 115RE, 132-136RE, UIC54, UIC60, 50Kg, Etc. Structure:: Ordinary Rail Joint
Standard:: BS, ASTM And DIN, Among Others. Numbers Of Holes: 4 Holes Or 6 Holes
Material: Q235,45#, 50# Package:: In Bundle With Pallets

Railway Fish Plates, rail joint bars for joint rail fish plate in railway



ZHONGYUE's railway fish plates, also called rail joints or joint bars, offer a different function to other rail components. Rail joints are flat metal plates usually used to connect adjacent two rails with a number of rail bolts or railroad spikes.



Traditionally, railway fish plates are drilled with some holes on the ends of the sections to be connected. There are some holes in the end of railway track, which are used lined up with the holes in the railway fish plate and jointed using a rail bolt. In general, railway fish plates are made of steel, but plastics and composites are alternative raw materials for rail joints.



Rail fish plate, also called rail joint bars, is one of the most common kinds of rail fasteners. Below is the specific information about rail fish plate.

Definition: to connect or joint rail tracks
A rail fishplate, also called splice bar or joint bar, is a device used to connect the ends of two rails with bolts in a track. It can be divided into 3 types according to light rail, heavy rail and crane rail. The preferred spare part to fix a rail joint bar is fish bolt set, which is always made of a fishtail bolt, rail nut, flat washer and spring washer. Every 2 fishplates (one unit) need 6 or 4 fish bolts.Definition: to connect or joint rail tracks
A rail fishplate, also called splice bar or joint bar, is a device used to connect the ends of two rails with bolts in a track. It can be divided into 3 types according to light rail, heavy rail and crane rail. The preferred spare part to fix a rail joint bar is fish bolt set, which is always made of a fishtail bolt, rail nut, flat washer and spring washer. Every 2 fishplates (one unit) need 6 or 4 fish bolts.
Function: to maintain the extended rail track’s continuity
There are bolt holes in the middle of a fishplate used in railway track. Above and below the hole horizontal axis, there are up and down working faces to touch the bottom of railhead and the top of rail flange, respectively. The backside of above mentioned up-working-face forms a transition section over the rail surface while extending upward, which becomes a bridge-arc of high in the middle but low at two ends, orientating along the length of the rail joint bars. Such bridge-arc frame is simple, capable of reducing the impact of carriage wheels to steel rail joints and strengthening the continuity of longitudinal strain at the steel rail joints in order to improve the train’s smooth passing.


Type Length/Diameter Weight(Kg)
115RE 4 hole- 24 ″ 17.04
115RE 6 hole -36 ″ 25.56
132-136RE 4hole-24 ″ 17.75
132-136RE 6hole-36 ″ 26.63
UIC60 4 hole - 630/ ¢ 26 18.07
UIC60 4 hole-600/ ¢ 28 17.47
UIC60 4 hole - 630/ ¢ 25 18.1
UIC54 4hole 14.34
UIC54 6hole- 800 19.94
BS80A 4hole 6.5
BS90A 685.8 / ¢ 26 13.23
BS90A 792.9/ ¢ 26 .2 15.34
90/91LB 4 hole 18.08
90/91LB 6hole 19.9
50Kg 4hole 14.3
50Kg 6hole 19.5
BS75R 4hole 6.56
BS60A 4hole 5.61
S49 4 hole 9.71



Types of railway fish plates
According to textures, railway track fishplates can be made of nodular cast iron, Q235 rolling and forging/blacksmithing. Models of the fishplates joint can be divided depending on rail weight such as 8kg, 12kg, 15kg, 18kg, 22kg, 24kg, 30kg, 38kg, 43kg, 50kg, 60kg,75kg, etc.

Surface requests of railroad fishplates
The fishplate is a connecting link between the preceding and the following steel rails. Therefore, if the quality of the fishplate is poor, the caused consequences would be unimaginable. Many quality inspection rules shall be followed during production, including surface requests as below:
The fishplate surface should be clean and smooth without any crack, scarring, scratches or any other defects. The end faces shall not be with any shrinkage cavity mark or intercalation. The allowed surface defects and relative geometrical quantity for both light and heavy rails shall be within the range of standard provisions.

A fishplate of rail track after rolling should be straight without significant bending or torsion.
Assembling and maintenance of fish plates in railway
To ensure the fine use of railway accessories and fittings including rail splice bars, it is necessary to maintain the fishplates from time to time, to improve the equipment quality and avoid any accidents. Assembling and maintenance standards of railway fish plates are as below:

The fishplates’ assembling device in place without any wounds or cracks; fish bolts well fixed.
Each connected rod or out-lock device is not found with any wounds or cracks. No grinding or corrosion on the rod body and abrasion pin hole less than 1mm with good insulation.

All iron rods’ insulation connection and the insulation link between out-lock iron and gauge rod are both fine. At uninsulated condition, 3mm gap shall be kept and not into other parts. Bolts are fixed well in place as well.

To guarantee none crack is found on the shell of the switch machine to install fishplates, and the installation is firm under good lock condition.

To ensure the oil tank circuit in good protected condition without any damage or being buried by ballasts or other debris.


Railway Fish Plates, rail joint bars for joint rail fish plate in railway 0Railway Fish Plates, rail joint bars for joint rail fish plate in railway 1Railway Fish Plates, rail joint bars for joint rail fish plate in railway 2
