Railroad Fastener Button Head Oval Neck Track Bolt with nuts and washers

Basic Information
Place of Origin: China
Brand Name: ZHONGYUE
Certification: ISO/SGS/TUV
Model Number: Fish bolt
Minimum Order Quantity: 5000pcs
Price: negotiation
Packaging Details: Plastic bags and wooden pallets or according to clients' requirement
Delivery Time: 10 working days after received your payment
Payment Terms: T/T or L/C
Supply Ability: 500,000set per month
Product Name: Railway Bolt Application: Railway
Grade: 4.9, 5.6, 8.8, 10.9 Material: Q235, 35#, 45#, 40Cr
Surface: Plain (oiled), Oxide Black, Zinc, HDG, Wax, Bitumen, Dacromet Standard: UIC864-2
Guarantee: 100% Meet Contract Tender Cooperation:: We Welcome Clients Ask Us To Bid New Tenders
High Light:

railroad bolts

,

hexagon head bolt

Railroad Fastener Button Head Oval Neck Track Bolt with nuts and washers


Specifications:

Fish Bolt



Fish bolt are used for splice bar connections and ZHONGYUE can supply a range of fish bolts manufactured to international standards according to BS, ASTM and DIN, among others.
Listed below are examples of some of our fish bolt manufactured over the last several years as per BS 20M, 30M, 35M, 35R, 50 O, 60A, 75R, 80R, 80A, 95RBH, and 113A; DIN S10, S14, S18, S20, S24, S30, S49, UIC54, UIC60; and AREMA 40ASCE, 60ASCE, 75ASCE, 90ARA, 115RE.


Railroad Fastener Button Head Oval Neck Track Bolt with nuts and washers 0Railroad Fastener Button Head Oval Neck Track Bolt with nuts and washers 1
1. This fish bolt is manufactured as per ASTMA-183. Track bolts come with heavy square nuts and Grade 2 heat treatment, with oval neck and diamond neck.

Tensile Strength

Yield Strength

Elongation

828Mpa (min)

635Mpa (min)

14%(min)

Material: 45#
Surface: Black
MOQ: 5000PCS
Packing: 200LB keg and wooden pallets or according to clients' requirement
Below are some of our main fish bolt products.
Button Head Oval Neck Track Bolt

Diameter

Length

Weight (Kg)

1/2"

1-3/4"

0.097

1/2"

2"

0.10

1/2"

2-1/4

0.112

5/8

2-1/2

0.183

3/4

3

0.328

3/4

3-1/2

0.339

3/4

4

0.356

7/8

4-1/2

0.559

7/8

5

0.593

1

5

0.8

1

5-1/2

0.839

1

6

0.879

1-1/16

6

0.995

1-1/8

6-1/2

1.186

Diamond Neck Track Bolts

Diameter

Length

Weight (Kg)

7/8

4-1/2

0.563

7/8

5-1/2

0.651

1

5-1/4

0.889

1

5-3/4

0.895

Note: All fish bolt dimensions given in inches
Material: Q235 and 45#
Grade: 4.8, 4.6, 5.6, .6.8, 8.8
Surface: Plain, black painting
MOQ: 5000PCS
Packing: Plastic bags and wooden pallets or according to clients' requirement

Nominal Size

Thread Length

Bolt Length

3/4

2

3-7/8

7/8

2-1/8

4-3/8

15/16

2-5/16

4-5/16

15/16

2-1/8

5

1

2-5/16

4-15/16

1

2-11/16

6-1/16

Note: All dimensions given in inches


Railroad Fastener Button Head Oval Neck Track Bolt with nuts and washers 2
2. We produce the fish plate bolt as per AS1085.4-1999. The nominal thread diameter is M20/M22/M24 and the thread of the fish bolts are finished square. A nominal 45 degree chamfer is to be provided to a depth slightly exceeding the depth of the thread, nut shall be in accordance with AS/NZS 1252.
Material: Q235 and 45#
Grade: 8.8
Surface: Plain, black painting
MOQ: 5000PCS
Packing: Plastic bags and wooden pallets or according to clients' requirement
Chemical composition and mechanical properties are shown below.

C

Mn

P

S

0.55(max)

0.25(min)

0.04(max)

0.04(max)



Tensile Strength

Yield Strength

Elongation

800Mpa

640Mpa

12%



Railroad Fastener Button Head Oval Neck Track Bolt with nuts and washers 3
3. We produce the fish bolts according the BS standard. These fish bolts can be manufactured to mild steel or high tensile steel Grade 8.8 as well as the latest Transnet specifications. Metric and imperial sizes are available and are used for fish plate of BS50, BS60R, BS70A, BS75A, BS75R, BS80A, BS80R, BS90A, BS90R, BS95A, BS95R, and BS95N.
Adhering to our quality first policy, ZHONGYUE pays great attention to quality control management on fish plate. We have been granted ISO9001-2008 certificates and have received the production license of China's Railway Ministry on railway products. We have a full set of inspection instruments to ensure all our fish bolt products are of high quality and up to customers' requirements.
As a leading manufacturer of rail fastening based in China, ZHONGYUE also produces many other railway fasteners, such as track spike, sleeper screw, rail anchor, rail joint bar, tie plate, rail clip, elastic rail clip, SKL tension clamp, rail shoulder, and so on.
