Railroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black Oxide

Good quality Railway Sleeper Screws for sales
After a comparison of the number of Rail Fastening System, I found that quality of ZY products is better than others. So choose ZY is right.

—— Jim

Recently cooperated with Suzhou Zhongyue,we are very satisfied.Not only their products but their services all very good.

—— Jack

I'm Online Chat Now

Railroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black Oxide

China Railroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black Oxide supplier
Railroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black Oxide supplier Railroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black Oxide supplier Railroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black Oxide supplier

Large Image :  Railroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black Oxide

Product Details:

Place of Origin: jiangsu China
Brand Name: zhongyue
Certification: ISO9001:2008
Model Number: 24x145mm

Payment & Shipping Terms:

Minimum Order Quantity: 10000PCS
Price: Negotiable
Packaging Details: Plastic bags and wooden pallets or according to clients' requirement
Delivery Time: 30 days after received your payment
Supply Ability: 500000PCS/MONTH
Contact Now
Detailed Product Description
Product Name:: Railway Track Bolts, Fish Bolts 24x145mm,45# Grade 8.8 With Black Oxided Colors Material:: 45#
Grade:: 8.8 Application:: Fastening Part
Main Surface Treatment:: Plain (oiled), Oxide Black, Zinc, HDG, Wax, Bitumen, Dacromet Package:: Woven Bag, Wood Pallet

railway track bolts, fish bolts 24x145mm,45# Grade 8.8 with black oxided colors

Track bolts are generally hexagon domed head bolts. They are used to secure the track plates to the track chains on crawler equipment such as bulldozers. Zhongyue track bolts are forged from alloy steels and heat-treated to the specifications of the original equipment manufacturers.

We also produce many double head screws each year according to clients' drawings or samples.

Track bolts are made in either inch-series with UNRF or UNRS threads, or metric with fine-pitch threads. They are secured by either square, hexagon or special domed track nuts.




Brand ZhongYue
Name Railway bolt
Type HS26/HS32
Russian clamp bolt & inserted bolt
Or the type by customers’ drawings
Grade 4.6 5.6 8.8 10.9
Material Q235 35# 45# 40Cr
Mechanical properties Tensile strength: ≥400Mpa Tensile strength:≥500Mpa Tensile strength:≥800Mpa Tensile strength:≥1000Mpa
Yield strength:≥240Mpa Yield strength:≥300Mpa Yield strength:≥640Mpa Yield strength:≥900Mpa
Elongation:≥22% Elongation:≥20% Elongation:≥12% Elongation:≥9%
Cold bending: 90 degree without crack Cold bending: 90 degree without crack Cold bending: 90 degree without crack Cold bending: 90 degree without crack
Surface plain (oiled), Oxide black, Zinc, HDG, wax, bitumen, Dacromet, Sherardizing
Standard refers UIC864-2

Railroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black Oxide


Railroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black OxideRailroad Track Bolts Fish Bolts 24 * 145mm 45# Grade 8.8 With Black Oxide




Established in 2013, ZhongYue has become one of the largest manufacturer of Railway fasteners in China. Our products are manufactured according to international standards such as ASTM, DIN, BS, JIS, AS, NF, ISO,GOST and GB. They are inspected frequently by BV, SGS, and ABS. We have been granted ISO9001:2008 certificate and supply products to famous companies such as VAE, Hilti,Vossloh etc. We are a qualified supplier of Canada railway, Kazakhstan railway, American railway, Zambia railway, Thailand railway, Indonesia railway, Malaysia railway, Sweden railway, New Zealand railway, South Africa railway etc.


Sticking to our quality first policy, ZhongYue pays great attention to quality control management. We have been granted ISO9001-2008 certificates and have received the production license of China's Railway Ministry on railway products. We have a full set of inspection instruments to ensure all our railway bolt products are of high quality and up to customers' requirements.



Aplication



Railway, Mining, Bridge, Construction and so on



Inspection machine for finished rail clips

Our main products:



We can provide products according to customers drawings and samples.Our main products are as following:
1. Screw spike/Coach screw/Drive screw/Sleeper Screw, Dog spike/Railroad spike/Lock spike/Cut spike,etc.
2. Rail clip/ Tension clamp/ E, R, SKL clip/ Pandrol clip/ Deenik clip
3. Swivel Bolts/ Track Bolt/ Special bolts/ U bolts/ J bolts/ Anchor bolts/ Foundation bolts/ Stud bolts/ Rod bolts/ Curved bolts/ Tunnel bolts
4. Tie plate/ Base plate / Rail plate/ Rail fixing base/ Rail Pads/ Sole plate/ Sole pad
5. Fish plate / Joint bar / Rail joint/ Splice Bar
6. Track bolt/ T bolt / Rail bolt/ Clamp bolt/ Inserted bolt/ Clip bolt/ Fish bolt/ Square bolt/ Rod bolt /Rail joint bolt
7. Clamp plate/ Rail spring clamp/ Anchor plate/ Steel clip
8. Rail Shoulder/ Rail sleeper Inserts/ Rail Anchors for rail sleepers
9. Plastic dowel / Guide plate/ Nylon insert
We are trying to supply the best products at the best price!



Custom Railroad Track Spikes , Threaded Screw Spike For Rail Fastening System



1. Q: what information should we show if we need price?

A: 1. tree species;

2. size: length*width*thicknessl;

3. quantity;

4. we adopt oiled anti corrosion, if yours special, please mark it.



2.Q: what is anti-corrosion?

A: Using high temperature and pressure oiling corrosion technology.
Technology standards : GB9221-88



3. Q: payment terms?

A: 30% by T/T as deposit, the balance 70% before delivery.



4. Q: Validity Date?

A: 10~15 days in general. it will be showed in quotation.



5. Q: Mold fee?

A: if we have same mold, no mold fee;

if we make new mold with small quantity, client pay for it;

if we make new mold with large quantity, SuYu pay for it.





If you have any other models of rail/ rail fastener, welcome to contact me.
