Customized S-13 Rail Clips With Material 60Si2MnA HDG Surface Treatment Coating

Basic Information
Place of Origin: China
Brand Name: ZHONGYUE
Certification: ISO9001:2008
Model Number: Rail Clip
Minimum Order Quantity: 5000pcs
Price: Negotiation
Packaging Details: 25Kg plastic bags and wooden pallets or according to clients' requirement
Delivery Time: 10 working days after received your payment
Supply Ability: 500,000pcs per month
Product Name: Rail Clip Application: Railway Fastening
Type: KPO3, KPO6, KPO9, Or Customized Material: Q235-forging, ZG35-cast Steel, QT500-7-cast Iron
Surface: Plain (oiled) Standard: DIN5906
Dimensions: According To Drawings Rail: ASCE30, ASCE50, UIC60, UIC54,BS90A,BS80A,115RE Etc
High Light:

fastening plate

,

din rail clips

Customized S-13 Rail clip with material 60Si2MnA HDG surface treatment coating



We offer various rail clamps, which are known for their high quality and strong durability. They are made of high-grade steel and conform to the defined parameters of railways and prevailing market demands. These rail clamps are available in varied specifications and can be customized according to customers’ specific requirements.



Their main features are as follows excellent designing; high quality; low maintenance; optimum performance; reliable; highly efficient; high tensile strength; long functional life; corrosion resistance.



Name Plain Surface Q235 Steel Railway Clip Rail Fastening Plate Variable Shapes And Models
Type used in 50Kg, 85Kg,90/91LB, 115RE /136RE ,UIC54 & UIC60 rail
  Or the type by customers drawings
Material 60Si2MnA 45# QT500-7
Chemical composition(%)

C:0.56-0.64, Mn:0.60-0.90, Si:1.60-2.00, Cr:≤0.35,

P:≤0.03, S:≤0.03

C:0.42-0.50, Mn:0.50-0.80, Si:0.17-0.37, Cr:≤0.25,

P:≤0.035, S:≤0.035

C:3.60-3.80, Mn:≤0.6, Si:2.50-2.90,

P:≤0.08, S:≤0.025

Surface plain (oiled),color painting
Standard refers

DIN, ISO, JIS, EN

Product Show

Customized S-13 Rail Clips With Material 60Si2MnA HDG Surface Treatment Coating 0



PACKAGE PHOTOS:



Customized S-13 Rail Clips With Material 60Si2MnA HDG Surface Treatment Coating 1

Customized S-13 Rail Clips With Material 60Si2MnA HDG Surface Treatment Coating 2





BAGS WITH PALLETS



Customized S-13 Rail Clips With Material 60Si2MnA HDG Surface Treatment Coating 3

Rail clip for North Africa Packing Method:

Double-layer woven bag+free-fumigation pallet; Steel Drum+Pallet; Wooden box; or upon customers' request.The rail clamp is packed in wooden boxes or sacks and wooden pallets. On average, 25kgs per package.





Material Technical Specifications

  1. Forging: Q235;
  2. Cast steel: ZG35;
  3. Cast iron: TQ500-7
Grade 4.6
Material Q235
Mechanical Tensile strength: ≥ 400Mpa
Yield strength: ≥ 240Mpa
Elongation: ≥ 22%
Cold bending: 90 degree
without crack



Name QT500-7 QT450-10 QT400-15
Standard GB 1348-88 GB 1348-88 GB 1348-89
Chemical composition(%) C:3.60-3.80 C:3.40-3.90 C:3.50-3.60
Mn:≤0.6 Mn:0.2-0.5 Mn:≤0.5
Si:2.50-2.90 Si:2.70-3.00 Si:3.0-3.2
P:≤0.08 P:≤0.07 P:≤0.07
S:≤0.025 S:≤0.03 S:≤0.02
Tensile Strength ≥500 Mpa ≥450 Mpa ≥400 Mpa
Yield Strength ≥320 Mpa ≥310 Mpa ≥250 Mpa
Elongation(%) ≥7 ≥10 ≥15
Hardnrss 170~230HB 160~210HB 130~180HB
Metallographic organization ferrite + pearlite graphite + ferrite + pearlite ferrite



Drawing

Plain Surface Carbon Steel KPO Type Rail Clip For DIN 536 And UIC 860 Standard Rail



Our main products:


Plastic and rubber pads, EVA pad, HDPE pad, dog spike, screw spike, railway bolt and nut, washer, rail clip, rail shoulder, crane rail, fish plate, base plate, crane rails and so on.



Custom Railroad Track Spikes , Threaded Screw Spike For Rail Fastening System





1. Q: what information should we show if we need price?

A: 1. tree species;

2. size: length*width*thicknessl;

3. quantity;

4. we adopt oiled anti corrosion, if yours special, please mark it.



2.Q: what is anti-corrosion?

A: Using high temperature and pressure oiling corrosion technology.
Technology standards: GB9221-88



3. Q: payment terms?

A: 30% by T/T as deposit, the balance 70% before delivery.



4. Q: Validity Date?

A: 10~15 days in general. it will be shown in the quotation.



5. Q: Mold fee?

A: if we have same mold, no mold fee;

if we make new mold with small quantity, client pay for it;

if we make new mold with large quantity, SuYu pay for it.





If you have any other models of rail/ rail fastener, welcome to contact me.
