ASTM Steel Railway Fish Plate With Square Head Bolts And Nuts

Basic Information
Place of Origin: China
Brand Name: ZHONGYUE
Certification: ISO/SGS/TUV
Model Number: BS80A
Minimum Order Quantity: 100 pcs
Price: negotiation
Packaging Details: 25Kg plastic bags and wooden pallets or according to clients' requirement
Delivery Time: 10 work days after getting payment
Payment Terms: T/T or L/C
Supply Ability: 500,000 set per month
Product Name: Fish Plate Application: Railway / Track / Railroad
Type: 115RE, 132-136RE, UIC54, UIC60, 50Kg, Etc. Material: 45#, 50#
Length: 4 Hole Standard: BS, ASTM And DIN, Among Others.
High Light:

railroad fish plate

,

rail joint bar

BS80A ASTM  Steel Railway Fish Plate With Square Head Bolts And Nuts​



Set Of Fishplate:

  1. Fishplate BS80A
  2. Square Head Bolt
  3. Hex Nut

Types of Fish plates:

  1. 4-Hole
  2. 6-Hole



Rail Joint Bar:


 1) Type: To 115RE; 132RE supporting the North America markets fish plates.
     To UIC54; UIC60 supporting the Europe, Asia and Africa fish plates.
     To TJ45; TJ57 supporting the South America markets fish plates.
     To BS60; BS75 supporting the British Commonwealth fish plates.
     Heterotypic fish plate: 43kg-50kg; 50kg-60kg; 60kg-75kg, 43kg-75kg common fish plate
     P50, P60 bulge fish plate
 2) Raw material: 45#, 50#, B7.45#
 3) Surface: plain (oil)



Main Parameter

Name

Specification

Equal to rails

Materials

Standard

of Products

Theory Weight

(kgs/set)

Length of

Dimension

(mm)

Packed In Bundle

With Iron Wire (set)

PlateFish

4/9kgs/M

Q235B or …

GB11265-89

0.80

≈270-385

50

1.00

12kgs/M

GB11265-89

1.10

≈409

50

1.30-1.50

15/18kgs/m

GB11265-89

1.80-2.00

≈372-409

25

2.20-2.50

2.80-3.00

22/24kgs/M

GB11265-89

3.30-3.50

≈426-510

20

3.80-4.00

4.20-4.50

30kgs/m

GB11265-89

5.50-7.50

≈561

10

8.20-8.50

38/43/50kgs/m

GB185-63

24-30

≈790



ASTM  Steel Railway Fish Plate With Square Head Bolts And Nuts 0ASTM  Steel Railway Fish Plate With Square Head Bolts And Nuts 1ASTM  Steel Railway Fish Plate With Square Head Bolts And Nuts 2
