9220 Steel Plate Weldable Upper Rail Clip With Rubber Nose and Base Clip for Crane Rail A100 QU100

Basic Information
Place of Origin: China
Brand Name: ZhongYue
Certification: ISO9001:2015
Model Number: 9220, 9120, 9116
Minimum Order Quantity: 2000sets
Price: Negociable
Packaging Details: 25Kg Cartons or woven bags in wooden pallet , 36bags/pallets , 24pallets/container or according to customers' requirement .
Delivery Time: 15-30 days after order
Payment Terms: T/T, 30% in advance
Supply Ability: 3000 Ton/Tons per Month
Product Name: Crane Clip Model: 9220, 9120, 9116
Material: Q235 Grade: 4.6, 4.8, 5.6
Surface: Plain, Zinc, Black Paint Etc Sample: Available
High Light:

crane rail clips

,

din rail clips

9220 Weldable Upper Clip With Rubber Nose

Plain Q235 Carbon Steel





The extensive Zhongyue clip range can accommodate nearly every rail profile produced in the world, including DIN Rail, MRS Rail, ASCE or “T” Rails and US Crane Rail sections, used either with or without crane rail pad. Two main clip types are available, based on the fixing support: either welded-base or through-bolted. Zhongyue offers clips for use with both imperial and metric hardware, and in both single-bolt and double-bolt configurations for all types.



crane rail clips maintain the rail lateral position but allow for needed longitudinal movement through the use of the vulcanize-bonded rubber nose. The nose helps absorb the energy of vertical deflection caused by wheel passes.



Zhongyue crane rail clips are manufactured throughout the world, with primary manufacturing in North America and Europe.



Specification



Item Name Two Hole Clamp
Usage Rail Fastening
Material Iron Steel
Surface Treatment Bluing, Plain Oiling, Color Painting, etc
Documents with Delivery Mechanical Properties, Chemical Composition, All Sizes Reports
Standard ISO, SGS, TUV





System



Two hole clip system



Item Part Quantity Size
1 Upper clip 1 150*92mm
2 Weldable clip 1 160*60mm
3 Rubber rod 1 140*13mm
4 Bolt 2 M20*55
5 Hex nut 2 M20
6 Washer 2 M21































Material



Forging: Q235;



Grade 4.6
Material Q235
Mechanical Tensile strength: ≥ 400Mpa
Yield strength: ≥ 240Mpa
Elongation: ≥ 22%
Cold bending: 90 degree
without crack



Note

the first 4: tensile strength of material Q235 is 400MPa;

the second 0.6: the yield ratio is 0.6;

the yield strength of material Q235 is 400MPa x 0.6 =240 MPa.


MOQ: 3.0 MT/ORDER
Packing: 25Kg plastic bags and wooden pallets or according to clients' requirement





Surface Treatment

  1. plain (oiled)
  2. oxide Black
  3. galavazing
  4. DHG

Inspection machine

  1. Brinell Hardness Tester
  2. Carbon and Sulfur Analyzer
  3. Rockwell Hardness Machine
  4. Automatic Impact Testing Machine
  5. Metallographic Microscope
  6. Automatic High-speed Analyzer
  7. Fatigue Testing Machine
  8. Metallographic Specimen Polishing Machine
  9. Metallographic Specimen Pointing Machine

Packing and Shipping

  1. 25 kg double-layer woven bag with free fumigation wooden pallent
  2. 36bags/pallets
  3. 20pallets/20ft



Similarity

  1. one hole clip system
  2. E clip system
  3. SKL clip system
  4. Nabla clip system
  5. dog spike system

9220 Clip, Steel Plate Weldable Upper Clip With Rubber Nose and Base Clip for Crane Rail A100 from Suyu

9220 Clip, Steel Plate Weldable Upper Clip With Rubber Nose and Base Clip for Crane Rail A100 from Suyu

9220 Steel Plate Weldable Upper Rail Clip With Rubber Nose and Base Clip for Crane Rail A100 QU100 2



Sale Range

  1. Rail fastening system
  2. Dog spike / Screw spike
  3. Bolt set
  4. Elastic clamp
  5. Rail anchor
  6. Rail shoulder
  7. Fish plate
  8. Tie plate
  9. Plastic / Rubber parts
  10. Brake shoe
  11. Steel rail
  12. New wood sleeper





For more information, welcome to contact me!
